An always-on "enhancer" designed to replace a traditional buffer. It sweetens and filters your guitar signal while converting it to low impedance, protecting it from anything that may follow in the rig.
Plug your guitar directly into HMBL's input, connect it after your favourite fuzz pedal, or insert it anywhere in your signal path for an instant improvement in tone.
Using even one BOSS pedal, some true-bypass pedals, and the associated patch cables, plus the usual longer guitar and amp cables, can make your tone sound and feel dark and sluggish. A buffer can help, but most are simple op-amp-based circuits that also introduce their sonic and technical limitations.
While HMBL can replace a traditional buffer, technically it is not one — it is a finely tuned amplifier with a sweetening circuit and filters that enhance your guitar signal. Use it in place of an input buffer by plugging directly into it. If you use a fuzz pedal, place it after that. It can also be used anywhere else in your signal path, even after the last pedal, to drive the long cable run to the back-line amp. It has an input impedance similar to that of a tube amp and presents a guitar (or a pedal) with a steadfast and ideal load that restores the resonant peak of your guitar pickups.
Like all Axess Electronics products, HMBL is made with genuine Neutrik and Switchcraft jacks and WIMA film capacitors. It boasts a modern, studio-grade op-amp and doesn't contain electrolytics in the signal path, which is why we consider it an Elite Enhancing Unity Amplifier (EEUA!), though we prefer to stay humble and not name it as such, etc.
Input Impedance: 1M ohm
Output Impedance: 50 ohm
Input Level: +11.4dBu / 2.9Vrms / 8.2Vpp (9VDC)
Input Level: +17.4dBu / 5.8Vrms / 16.4Vpp (18VDC)
Dimensions: 3.72 x 1.56 x 1.28in. / 94.5 x 39.5 x 32.5mm
Power Requirements: 9-18VDC 100mA via a 2.1 x 5.5mm barrel plug with a negative centre pin (like BOSS pedals). An adapter is not included.
Specifications subject to change without notice.
